Victaulic® Vic-Ball® V024726P0A 726 2-Piece High Pressure Ball Valve With Gear Operator, 2-1/2 in Nominal, Grooved End Style, Ductile Iron Body, Standard Port, Glass RPTFE/Fluoroelastomer Softgoods


Description

Victaulic® Vic-Ball® Ball Valve, 2-Piece High Pressure, Series: 726, 2-1/2 in Nominal, Grooved, 1000 psi, 60 deg F, Standard Port, 1.97 in Orifice, Lever Operated Actuator, Carbon Steel Ball, 4 in Top to Inlet Center, Ductile Iron Body, Glass RPTFE/Fluoroelastomer, Zinc Plated, 2-7/8 in OD

High-pressure standard port ball valve with grooved ends. 2-Piece, end-entry valve. Features floating ball for lower torque requirements.

Specifications

Actuator Type Lever Operated
Ball Material Carbon Steel
Body Material Ductile Iron
Dimensions 2-7/8 in OD
End Style Grooved
Finish Zinc Plated
Nominal Size 2-1/2 in
Orifice Size 1.97 in
Port Type Standard
Pressure Rating 1000 psi
Series 726
Softgoods Material Glass RPTFE/Fluoroelastomer
Temperature Rating 60 deg F
Top to Inlet Center 4 in
Type 2-Piece High Pressure

Standards and Approvals: ASTM A536 Grade 65-45-12, ASTM A-395, ASME A17.1-2007, CSA B44-07 Certified, NACE Certified

Features

  • Glass RPTFE and fluoroelastomer seal
