Jomar Valve® 100-708 2-Piece Ball Valve With Handle, 2 in Nominal, NPT End Style, Brass Body, Full Port, FKM/Hostaflon® TFM Softgoods, Import


Description

Jomar Valve® Ball Valve, 2-Piece, 2 in Nominal, NPT, 500 psi WOG, Full Port, TEA Coated Brass Ball, 5 in Inlet to Outlet Length, 3.4 in Top to Inlet Center, Brass Body, Brass Stem and Hostaflon® TFM 1600 Seat Trim, FKM/Hostaflon® TFM Softgoods, Import

Specifications

Ball Material TEA Coated Brass
Body Material Brass
Domestic/Import Import
End Style NPT
Inlet to Outlet Length 5 in
Nominal Size 2 in
Port Type Full
Pressure Rating 500 psi WOG
Softgoods Material FKM/Hostaflon® TFM
Top to Inlet Center 3.4 in
Trim Material Brass Stem and Hostaflon® TFM 1600 Seat
Type 2-Piece

Warranty: Lifetime Limited

Country of Origin: Italy

Standards and Approvals: ANSI B1.20.1, CW617N Body, CSA Certified, FM Approved, MSS SP-110

Features

  • Blow-out proof stem
  • Triple sealing stem with (2) FKM O-Rings and PTFE seal
  • 100% leak tested
  • Leak-proof stem lifetime warranty
  • 29 in-Hg vacuum rating
  • 150 psi steam working pressure
  • FKM O-ring and hostaflon® TFM 1600 packing
