APG 13880FF125A0150FC Full Face Gasket, Styrene Butadiene Rubber, 1-1/2 in Nominal, 5 in OD x 1/8 in THK, Class 150, Domestic


Description

APG Gasket, Full Face, 1-1/2 in Nominal, 1-29/32 in Inside Dia, 5 in Outside Dia, 1/8 in Thickness, 4 Bolt Holes, 5/8 in, Class: Class 150, -10 to 200 deg F, Styrene Butadiene Rubber, Smooth, Red, Domestic

Specifications

Bolt Hole Size 5/8 in
Class Class 150
Color Red
Domestic/Import Domestic
Finish Smooth
Inside Diameter 1-29/32 in
Material Styrene Butadiene Rubber
Nominal Size 1-1/2 in
Number of Bolt Holes 4
Outside Diameter 5 in
Temperature Rating -10 to 200 deg F
Thickness 1/8 in
Type Full Face

Country of Origin: United States

Application:
For heating and plumbing trades

Features

  • Styrene butadiene rubber sheet
  • Recommended for low applications such as washers and gaskets for the heating and plumbing trades
  • Low cost flange gasket material
  • Non-oil resistant compound that resists flow under compression
  • Offers moderate to good performance against low pressure
  • Good aging and abrasion resistance
  • Easily conforms to uneven flange surfaces
  • 3-7/8 in bolt hole circle
  • 500 psi tensile strength
  • 75 +/- 5 Durometer meter hardness shore A
