Victaulic® G040077LT0 Grade T Gasket, 4 in Nominal, Nitrile


Description

Victaulic® Gasket, Grade T, 4 in Nominal Size, -20 to 180 deg F, Nitrile, Orange

This seal selection guide is separated into four discrete sections: Gasket seals for Couplings, Seals for Vic-Press®, O-Rings for Victaulic Bolted Split Sleeve Products and General Definition/Seal Material Selection. This publication does not include Victaulic seals for valves. Refer to the individual Victaulic valve submittal for information on the seals available for each valve.

Specifications

Color Orange
Material Nitrile
Nominal Size 4 in
Temperature Rating -20 to 180 deg F
Type Grade T

Standards and Approvals: ANSI/NSF 61/372, UL Listed

Features

  • Recommended for petroleum products, hydrocarbons, air with oil vapors, vegetable and mineral oils within the specified temperature range
  • Not recommended for hot dry air over 140 deg F and water over 150 deg F
  • Not recommended for hot water services
  • For use with 07-75-77 couplings
